Multi-channel Optical Link Selector

Description

Optical Link selector is mainly used in multi-channel optical monitoring of optical transmission system, LAN multi-source/detector auto-exchange, optical sensing multi-point dynamic monitoring system, cable test of optical fiber, optical devices, networks and field projects in optical test system, optical device debugging and installation, monitoring multi-link network data security in data security,etc.

Features
· Low insertion loss, fast switching
· Hot backup of double power supply, support hot-plugging.
· LED display panel. Visual display, convenient operation.
· Transparent transmission signal. High stability and reliability.
· Channel and time interval of automatic scanning can be set up.
· Support WEB、SNMP、TELNET、SSH, FTP log download,etc

Specifications

Parameters	Unit	SUN-OSW-N
Channel No.		16 to 2（D1×8）	32 to 2（D1×16）
Test Wavelength	nm	1310 / 1550
Insertion Loss	dB	Typ: ≤ 0.6dB， Max: ≤ 1.0 dB
Repeatability	dB	≤ ±0.05
Return Loss	dB	≥ 45
Crosstalk	dB	≥ 70
WDL	dB	≤ 0.25
PDL	dB	≤ 0.1
Switching Time	ms	≤ 10 ms（Sequence switch time of adjacent channel）
Connector		LC / PC
Monitoring Port		RJ45、RS-232
Working Power Supply （Plug-type）	V	AC:100 ～ 240（50/60Hz） or DC: 36 ～ 72
Power Consumption	W	＜ 10
Operating Temperature	℃	-5 ～ 55
Storage Temperature	℃	-20 ～ 70
Chassis Type		1U standard 19 "rack（482.6×303×44mm） 2U standard 19 "rack（482.6×303×89mm）
Note：Customization is available.

Ordering Information

SUN-OSW-N-A-B-C-D-E

N

A

B

C

D

E

Channel No.

Fiber Type

Operating Wavelength

Power Supply Mode

Connector

Chassis Size

D1×8: 16 to 2

D1×16: 32 to 2

X:Others

SM:9/125 Single mode

M6:62.5/125 multimode

X: Others

13/15: 1310/1550nm

850: 850nm

X: Others

AC: 100~240V

DC: 36~72V

AC/DC: 100~240V&36~72V

AC/AC: dual 100~240V

DC/DC:dual 36~72V

X: Others

LP: LC/PC

X: Others

1U: 482.6×303×44mm

2U: 482.6×303×89mm

X: Others
